Fuer den Mikroskopeinsatz haben wir ein Objektiv Antrieb entwickelt, der sehr schnell, hochaufloesend und langzeitstabil ist. Desweiteren bieten wie einen einzigartig grossenen Verfahrbereich von 15mm und zwei Schnellverschluesse fuer den Antrieb selber und fuer die Objektive an. Passend dazu gibt es verschieden Nanopositioniere mit Interferometerpraezision. 3x kaeftiger und 100x praeziser als vergleichbare Wetbewerbprodukte durch eigenen Nanosensor. . . . . . . . . . . .
the pecker 15mm travel range, 0,5nm resolution, zero drift 1um within 1ms stainless/invar/titan/ double quick look system 25N force
. Pecker_15.pdf the LPS-60A travle range: 30mm / 30mm aperture resolution down to 0,5nm zero drift and homing force: 6/12N stainless/invar/titan standard/ UHV/nonmagnetic. . LPS-60A.pdf
the theta-table piezo moto stage travle range: 360 degree / 12,8mm aperture resolution up to 15mio counts/ turn zero drift and homing force: 90mNm stainless standard/ vacuum fit direct to the LPS-30 . RPS_LW20.pdf ____________________________________________________________________________________ the torque master table piezo motor system travle range: 360 degree resolution 129.600 counts/ turn zero drift and homing force: 100mNm.Very tiny system stainless standard/ vacuum fit direct to the LPS-30 . torque master table.pdf
|
